Exfo Maxtester Series Max 945Icert Q1EaEi

Product Description

ON SALE Exfo Maxtester Series Max 945-Icert-Q1-Ea-Ei OLTS Quad. This product is designed for precise testing and inspection of fiber optic systems.

Key Technical Specifications

• Wavelengths : 850, 1300, 1310, and 1550 nm
• Fiber Type : Multimode (50/125 µm, Encircled Flux compliant) and Singlemode (9/125 µm)
• Measurements : Insertion Loss (IL), Fiber Length, and Optical Return Loss (ORL – for singlemode only)
• Measurement Speed : Certifies two fibers at two wavelengths in 2.6 seconds (FasTesT duplex mode) or a single fiber bidirectionally in 5 seconds (FasTesT simplex mode)
• Length Range : Multimode: 20 km; Singlemode: 160 km
• Display : 7-inch, high-resolution outdoor-enhanced touchscreen (800 x 480 TFT)
• Connectivity : Two USB 2.0 ports, RJ45 LAN (10/100 Mbit/s), Optional Wi-Fi and Bluetooth capability
• Storage : 6 GB internal memory, capable of storing over 150,000 test results
• Battery Life : 12 hours of typical operation with a rechargeable lithium-polymer battery
• Dimensions (H x W x D) : 166 x 200 x 68 mm (6 9/16 in x 7 7/8 in x 2 ¾ in)
• Weight : 1.5 kg (3.3 lb) with battery
• Connector Interface : EA (Angled Physical Contact/APC) for the singlemode port and EI (Ultra Physical Contact/UPC) for the multimode port, with swappable SC adapters included.

MaxTester Series Max 945 model offers a comprehensive solution for testing and certification of fiber optic networks, making it an essential tool for businesses and professionals in the industry.
