USED RADIANT VISION SYSTEMS IC-PMI29-XBND3 Colorimeter

Product Description

RADIANT VISION SYSTEMS IC-PMI29-XBND3 Internal Filters Imaging Colorimeter
We confirmed that the computer was able to recognize the camera after we installed the software that was provided. A computer is not provided. Imaging colorimeter for post-RADIANT VISION SYSTEMS IC-PMI29-XBND3 internal filters.

RADIANT VISION SYSTEMS IC-PMI29-XBND3 Details:

• Primary Application: Production Line Testing
• CCD resolution (pixels): 6576 x 4384
• Total Megapixels: 28.8
• CCD Type: Interline, cooled to +5oC.
• CCD A/D dynamic range: 12 bits = 4096 gray scale levels
• High Dynamic Range (multi exposure): 1,000,000:1
• LuminanceMaximum: 1010 cd/m2 with optional ND filters
• Communication Interface: Ethernet 100/1000, USB 2.0 and 3.0 compatible
• Power: 100-240 V, 50-60 Hz, 140 Watts
• LCD Touch panel: Resolution: 800 x 600 Diagonal: 125 mm
• Dimensions (H x W x D): 238 mm x 181 mm x 230 mm
• Weight: 4.9 kg
• Operating temperature: 0 – 30° C
• Operating humidity: 20 – 70% non-condensing
